first_img SK Hynix plans to place a bulk order for next-generation HBM hybrid bonding equipment from BESI

According to Seoul Economy on November 20, SK Hynix plans to place initial orders for next-generation high-bandwidth memory hybrid bonding equipment used to stack DRAM to 16 layers and above in bulk to the Dutch equipment supplier BESI. The company has transported BESI equipment to its facility in Cheongju, North Chungcheong Province for trial operation, and subsequent equipment is also planned to be supplied by BESI. The semiconductor equipment industry states that SK Hynix is verifying the DRAM bonding performance with BESI equipment at the Cheongju campus. Hybrid bonding reduces the chip spacing by directly bonding DRAM chips. BESI has been jointly developing hybrid bonding systems with Applied Materials in the United States for the past six years.During a performance conference call on the 22nd of last month, BESI stated that it received orders for hybrid bonding equipment for HBM development and next-generation thermal compression bonding equipment from a major memory manufacturer in the third quarter, which Seoul Economy identified as SK Hynix. SK Hynix is currently testing two hybrid bonding devices in Cheongju to verify quality, one of which is supplied by BESI, and the other is from Hanwha Semitech, a subsidiary of Hanwha Vision. Hanmi Semiconductor is developing hybrid bonding equipment at the request of SK Hynix, but it has not yet reached the stage of delivering evaluation equipment.SK Hynix's adoption of hybrid bonding is due to the increased difficulty in controlling the overall thickness of HBM within specifications as the number of DRAM die stacking layers increases. The existing process places metal bumps that transmit electrical signals between DRAM dies, while hybrid bonding bonds the copper contacts and insulating film on the chip surface without bumps, thereby utilizing the space occupied by bumps for further stacking. Industry insiders indicate that BESI's hybrid bonding equipment can control the alignment error of the copper contacts between the upper and lower chips to within 100 nanometers, while the error for Korean equipment such as Hanmi Semiconductor and Hanwha Semitech is about 500 nanometers, which may only be used in some mass production lines in the future.

first_img SemiAnalysis: ASML is currently developing hybrid bonding equipment

On October 15, the semiconductor research organization SemiAnalysis published an article stating that the lithography equipment manufacturer ASML has not officially announced related products, but patents, news reports, and the company's roadmap all indicate that it is developing hybrid bonding equipment. The author of the article judges that ASML may first launch more challenging chip-to-wafer hybrid bonding tools and view it as an extension of vertical integration.Patents show that the system operates on a track, with each chip placed in an independent carrier, sequentially completing inspection, cleaning, plasma activation, morphology inspection, leveling, coarse alignment, position adjustment, and fine alignment before entering the bonding station; the final placement is completed by the carrier and suction cup. The track's repeat accuracy is about 10 microns, far from the approximately 50 nanometers required for bonding. ASML submitted 27 bonding patent families from December 2022 to November 2024, most of which are aimed at chip-to-wafer. The Elec reported in March that ASML has begun hybrid bonding machine architecture design with Prodrive Technologies and VDL ETG.The article states that wafer-to-wafer hybrid bonding has been used for image sensors and 3D NAND; chip-to-wafer is currently only used for mass production of logic chips, including AMD's hybrid bonding V-Cache shipped since 2022 and TSMC's SoIC. The current spacing of SoIC is about 6 microns, with a target of reaching approximately 4.5 microns by 2029. Besi is currently the only supplier with chip-to-wafer mass production tools, with related logic business mainly concentrated in TSMC and Intel.
